Corning 12 Strand 50/125 Multimode OM3 Indoor Plenum Fiber Optic Cable - Aqua (Per Foot)

$2.00
Reference#: 69105
Item#: COR-012T88-33180-29



Description

Corning cable systems MIC plenum cables are designed for use in plenum, riser and general purpose environments for intrabuilding backbone and horizontal installations. These multi-fiber cables use 900 um TBII Buffered Fibers to allow easy, consistent stripping and to facilitate termination. The fibers are surrounded by dielectric strength members and protected by a flame-retardent outer jacket. The all-dielectric cable construction requires no grounding or bonding. For additional mechanical durability, an interlocking armored option is available.

This Corning OM3 Fiber is Sold Per Foot

Features

  • 900 um TBII buffered Fibers allow for easy and consistent stripping
  • All-Dielectric cable construction requires no grounding or bonding
  • Flame-retardant jacket is very rugged and durable
  • 10 Gigabit Ethernet
  • 10-Gigabit Ethernet (sometimes expressed as 10GBASE-T, 10GE, 10GbE or 10 GigE), is a telecommunication technology that offers data speeds up to 10 billion bits per second. 10GbE was standardized inIEEE 802.3a.
  • Built on the Ethernet technology used in most of today's local area networks (LANs), 10-Gigabit Ethernet has been described as a "disruptive" technology that offers a more efficient and less expensive approach to moving data on backbone connections between networks while also providing a consistent technology end-to-end. Using optical fiber, 10-Gigabit Ethernet can replace existing networks that use ATM switches and SONET multiplexers on an OC-48 SONET ring with a simpler network of 10-Gigabit Ethernet switches and at the same time improve the data rate from 2.5 Gbps to 10 Gbps.
  • 10-Gigabit Ethernet is used to interconnect local area networks (LANs), wide area networks (WANs), and metropolitan area networks (MANs). 10-Gigabit Ethernet uses the familiar IEEE 802.3 Ethernet media access control (MAC) protocol and its frame format and size. Like Fast Ethernet and Gigabit Ethernet, 10-Gigabit Ethernet uses full duplex transmission, which makes possible a considerable distance range.

Specification

Nominal Weight (lb/1000ft)
  • 26 lbs
Nominal Outer Diameter
  • 0.24 in
Minimum Bend Radius
  • Loaded:  9.2 cm (3.6 in)
  • Installed:  3.1 cm (1.2 in)
Maximum Tensile Loads
  • Short-Term: 440 N (100 lbf)
  • Long-Term: 132 N (30 lbf)

Temperatures

  • Storage: -40­°C­ to ­+70­°C­­ (-40­°F­to­158­°F)
  • Installation: 0° to +60°C (+32° to +140°F)
  • Operation: 0° to +70°C (+32° to +158°F)
Approvals and Listings
  • National Electric Code ® ( NEC®) OFNP, CSA FT-6, ICEA S-83-596
Flame Resistance
  • NFPA 262 (For Plenum, riser and general building applications)
