Corning 24 Strand 62.5/125 Multimode OM1 Indoor/Outdoor Riser Fiber Optic Cable - Black (Per Foot)

$3.94
Reference#: 69134
Item#: COR-024K8F-31130-29



Description

Corning Cable Systems FREEDOM One Riser Cables are flame-retardant, UV-resistant, indoor/outdoor cables designed for aerial, duct and direct-buried applications with no need for a transition splice when entering the building. Available in fiber counts of six, 12, 18 and 24 fibers, the tight-buffered construction facilitates easier termination for low-fiber-count applications in the local area network (LAN) and eliminates need for fan-out kits.

The design features TIA-598 color-coded 900 µm TBII Buffered Fibers for easy identification, consistent stripping and direct termination. Available in 50 µm, 62.5 µm, single-mode and hybrid versions, the cable design meets ICEA S-104-696 test criteria and is also OFNR and FT-4 listed for riser and general purpose use. The small diameter and bend radius of the cable allow for easy installation in space-constrained areas while the innovative water-blocking technology is ideal for OSP applications.

Features

  • Water-blocking technology for outside plant applications
  • Small diameter and bend radius for easy installation in space constrained areas
  • Color coded for easy identification and consistent stripping
  • UV resistant, flame-retardant jacket – rugged, durable and easy to strip
  • This cable is PVC rated and sold per foot

Specification

Nominal Weight (lb/1000 ft)
  • 38
Nominal Outer Diameter
  • 0.30 in
Minimum Bend Radius
  • Loaded:  11.4 cm (4.5 in)
  • Installed: 7.6 cm (3.0 in)
Maximum Tensile Loads
  • Short-Term: 1335 N (300 lbf)
  • Long-Term: 400 N (90 lbf)
Temperatures
  • Storage -40° to +70°C  ( -40° to +158°C)
  • Installation: -10° to +60°C  ( +14° to +140°C)
  • Operation: -40° to +70°C  ( -40° to +158°C)
Approvals and Listings
  • National Electrical Code® (NEC) OFNR, FT-4
Design and Test Criteria
  • ICEA S-104-696
