Belden 22 awg 3 conductors solid bare copper shielded white CMP 75C 1000ft box

$384.00
Reference#: 68574
Item#: BE-6521FE



Description

22 AWG bare copper conductors, Flamarrest® insulation, conductors cabled, Overall Beldfoil® tape shield (foil side out) and drain wire, Flamarrest® jacket with ripcord, sequential footage marking every two feet.

Specification

CONDUCTOR: Gauge (AWG)
  • 22 AWG (AMERICAN WIRE GAUGE)
CONDUCTOR: Count
  • 3 CONDUCTORS
Cond. Type
  • SOLID CONDUCTOR
Material
  • BARE COPPER
Plenum:
  • YES IS A PLENUM CABLE
Insulation Material:
  • LSPVC-LOW SMOKE POLYVINYL CHLORIDE
SCREEN/SHIELD:
  • YES CABLE HAS SHIELDING
Shield Type
  • FOIL SHIELDED - ALUM/MYLAR
Construction
  • OVERALL SHIELD & DRAIN
JACKETING: Material
  • LSPVC-LOW SMOKE POLYVINYL CHLORIDE
Color Code
  • WHITE
SPEC NBR: UL Style
  • UL LSTED WIRE MISC.
NEC Rating
  • UL LISTED ART 800 PLENUM
CSA
  • FLAME RATED
Temperature Rating:
  • 75 DEGREES CENTIGRADE
Voltage Rating:
  • 300 VOLTS AC
RoHS Compliant:
  • YES
Conductor Size AWG
  • 22
Conductor Strand
  • Solid
No. of Conductors
  • 3
Insulation Thickness (in.)
  • 0.009
Jacket Thickness (in.)
  • 0.015
Approx. Wt. lb./1,000 ft.
  • 35
Approx. Wt. lb./1,000 ft. Alum. Shield
  • 13
Nom. O.D. (in.)
  • 0.190
Unspsc Code
  • 26121613
