Corning 96 Strand Singlemode Indoor/Outdoor LT Riser Fiber Optic Cable - Black (Per Foot)

$3.88
Reference#: 69159
Item#: COR-096EUF-T4101D20



Description

UTILITY
The Corning 96-Strand Single-Mode Indoor/Outdoor LT Riser Black Fiber Optic Cable from Discount Low Voltage is craft-friendly and can save you time. Thanks to the innovative water-blocking tapes and yarns in these Corning cables that swell to absorb water, you get outdoor as well as indoor use but don’t have to deal with messy gels.
AVAILABILITY
Because it is riser rated for indoor use but also has an outdoor-rated jacket built with UV and water protection, this Corning cable provides an easy transition from outside to inside with no need for splicing. It is ideal for interbuilding and intrabuilding backbones in aerial, duct and riser applications.
·Color-coded tubes and fibers for easy identification
·All-dielectric construction requires no bonding or grounding
·UV-resistant, flame-retardant jacket is easy to strip, rugged and durable
VALUE
Save even more when you take advantage of our quantity discounts available on this quality cable. In addition, if you are looking for Corning pre-terminated fiber, we can do the work for you inexpensively and quickly.
This cable is eligible for free shipping on qualified orders.
RESOURCES
Enjoy our Product Quick View video for a great look at this multi-purpose fiber. Don’t forget to download the Corning spec sheet. For answers to your questions, call our expert staff toll-free or send us an email.

Features

  • Riser rating: No transition splices when entering buildings
  • Gel-free waterblocking technology: Craft-friendly cable preparation
  • Color-coded tubes and fibers: Quick and easy identification
  • All-dielectric construction: Requires no grounding or bonding
  • UV-resistant, flame-retardant jacket: Rugged, durable and easy to strip

Specification

Nominal Weight (lb/1000 ft)
  • 168
Nominal Outer Diameter
  • 0.7 in
Minimum Bend Radius
  • Loaded: 7 in ( 177 mm)
  • Installed: 10.5 in (266 mm)
Maximum Tensile Load
  • Short-Term:  2700 N (600 lbf)
  • Long-Term: 810 N (180 lbf)
Temperature Range
  • Operating: -40ºC to +70ºC
  • Storage:-20ºC to +70ºC
  • Installation: -10ºC to +60ºC
Common Installations
  • Outdoor lashed aerial and duct; indoor when installed according to National
    Electrical Code® (NEC®) Article 770
Design and Test Criteria
  • ANSI/ICEA S-104-696
