Corning 48 Strand 62.5/125 Multimode OM1 Outdoor Armored Direct Burial Fiber Optic Cable - Black (2,000ft minimum)

$10.80
Reference#: 69155
Item#: COR-048KUC-T4130D20



Description

This is Corning Cable Systems Altos fiber optic cable is designed for outdoor and limited indoor use for campus backbones in lashed aerial and duct installations.

The loose tube gel-free design is fully waterblocked using craft-friendly, water-swellable materials, which means cable access is simple and no clean up is required. The flexible craft-friendly buffer tubes are easy to route in closures and the SZ-stranded,loose tube design isolates fibers from installation and environmental rigors while allowing easy midspan access. The all-dielectric cable construction requires no bonding or grounding and these cables have a medium-density polyethylene jacket that is rugged, durable and easy to strip. A variety of fiber types are available including 62.5, 50, single-mode and hybrid versions, as well as fibers with Gigabit Ethernet and 10 Gigabit Ethernet performance.

Note: Minimum Order Quantity - 2,000ft
To order, add ANY length above 2,000ft in "Add to Cart" box.

Features

  • Fully waterblocked loose tube gel-free design Simple access and no clean up
  • Medium-density polyethylene jacket All-dielectric cable construction Rugged, durable and easy to strip
  • Requires no grounding or bonding
  • Ready for any application including Gigabit Ethernet and 10 Gigabit Ethernet

Note: Minimum Order Quantity - 2,000ft
To order, add ANY length above 2,000ft in "Add to Cart" box.

Specification

Nominal Weight (lb/1000 ft)
  • 87
Nominal Outer Diameter
  • 0.48 in
Minimum Bend Radius
  • Loaded:  121 mm (4.8 in)
  • Installed: 182 mm (7.2 in)
Maximum Tensile Loads
  • Short-Term: 2700 N (600 lb)
  • Long-Term: 890 N (200 lb)
Temperatures
  • Storage -40°C to 70°C (-40°F to 158°F)
  • Installation: -30°C to 70°C (-22°F to 158°F)
  • Operation: -40°C to 70°C (-40°F to 158°F)
Application
Aerial, Direct Buried, Duct

Note: Minimum Order Quantity - 2,000ft
To order, add ANY length above 2,000ft in "Add to Cart" box.
