OCC 12 Strand Multimode 50/125 OM3 Indoor/Outdoor Riser Fiber Optic Cable - Aqua

$1.72
Reference#: 77942
Item#: OCC-DX012DALT9QR



Description

The DX012DALT9QR is a high-performance, 12-fiber distribution cable designed for both indoor and outdoor use, specifically built for applications requiring tight-buffered fiber optic solutions. This cable is ideal for installations in intra-building backbone and inter-building campus environments, offering a seamless transition between indoor and outdoor fiber systems without the need for costly junctions or changes in cable types. With its 50/125 OM3 multimode fiber, this cable supports high-bandwidth applications, making it perfect for demanding communication systems, data centers, and network infrastructures.

Features

  • High-performance components and construction
  • Cable materials are indoor/outdoor - UL-listed OFNR and UV, water and fungus-resistant
  • UL Listed in accordance with NEC section 770.179(b) for use in vertical runs in building riser shafts or from floor to floor
  • Helically stranded core for greater flexibility and mechanical protection of the optical fibers
  • High strength-to-weight ratio
  • Fiber configuration is smaller and lighter than comparable sub-grouped cables made by others: ideal for installation in areas with limited space or tight bends
  • Can be armored for additional protection in direct burial and aerial installations

    • Specification

    Operating Temperature: -40°C to +85°C
    Storage Temperature: -55°C to +85°C
    Install Temperature: -10°C to +60°C
    Flame Retardancy: UL listed type OFNR (UL 1666) for all fiber counts *FT4 (CSA C22.2 No. 232) for 2-24 fiber counts only
    Crush Resist: 1800 N/cm
    Impact Resist: 1500 impacts
    Flex Resist: 2000 cycles
    Jacket: Type D
