Dynacom Cat5e 12 Port Rackmount Patch Panel

Reference#: 69679
Item#: DY-2013-12C5E


Dynacom Cat5e 12 Port Rack Mount Patch Panel

12 Port, Cat5e, 1 rack mount space 1.75" Designed with rear 110 IDC for fast termination. Includes #12 rack screws and cable management bar.

Manufactured by Dynacom. Dynacom has provided data and telecom cable installers trusted connectivity solutions since 1984. Our commitment to quality products has made us a leader in supplying copper and fiber optic structural cabling products that exceed performance demands while maintaining exceptional value.


- 12 port 19" rack mounted Cat5e component rated patch panel provides excellent performance for data networks requiring maximum speed and bandwidth

- Enhanced crosstalk cancellation reduces return loss and improves performance by rejecting noise and unwanted signals for this 12 port patch panel

- This 12 port patch panel exceeds ANSI/TIA/EIA-568-B.2 Cat5e connecting hardware requirements

- Engineering to provide 110 IDC termination reducing installation time and making installation of this patch panel easier

- Includes both TIA-568A and TIA-568B color wiring diagrams

- Backwards compatible to all lower rated category components

- 12 port Cat5e patch panel installation instructions included

- UL listed


Warranty Information:

Dynacom products are built under rigid documented procedures. We are confident in their uniformity and conformity to the highest industry standards and warranties all of it's TIA, 568-A compliant Premises Network Wiring Products for 25 years. For all the details, download the Dynacom Warranty Form under the "Downloads" tab.
