Caddy MP1P Single-Gang Drywall Mounting Ring (Sold Individually)

Erico Caddy MP1P Single-Gang Low Voltage Mounting Bracket

The Erico Caddy MP1P has no sharp metal edges with new plastic design and is the easiest way to install a wall ring. The MP1P Mounting Plate allows for the installation of low voltage datacomm and alarm devices into drywall without installation tools. The bracket eliminates the need for electrical boxes on low voltage Class 2 applications. A serrated interlocking system secures the bracket tightly to drywall. The plastic design has no sharp edges and provides the industry with the widest application range of 1/4” to 1-1/4”.

• No tools required once hole is cut

• Template points on brackets eliminate multiple measurement markings during installation

• Recessed design assures flush mount of device

• Eliminates the need for electrical boxes on low voltage class 2 applications

• For communications, cable TV and computer wiring

• Cat5 listed

• Serrated interlocking system secures tightly

• Widest application range available today – wall thicknesses from 1/4” to 1-1/4”

• Available in single gang, double gang and a unique 3-4 gang version

Part Number: MP1P
Material: Acrylonitrile Butadiene Styrene
Finish: Plain
Gang: 1
Drywall Thickness: 1/4" – 1 1/4"
Certifications: cULus
Standard Packaging Quantity: 10 pieces (Sold Individually)
UPC: 78285635565
EAN-13: 8711893027990
