Specified Technologies STI FP400 Firestop Plug 4" (102 mm)

$48.95
Reference#: 73398
Item#: FP400



Description

SpecSeal® Series FP Intumescent Firestop Plugs are de-signed for temporary or permanent sealing of single or grouped cables and blank openings through common construction such as concrete or gypsum board. SpecSeal® Series FP Intumescent Firestop Plugs are soft, supple foam plugs molded from polyurethane. Plugs are conveniently sized to fit 2 or 4 in. (51 or 102 mm) diameter openings or sleeves fabricated from electrical metallic tubing (EMT). The intumescent plugs expand when exposed to heat to quickly close off around combustible jacketed cables.

Common Applications:

  • Conduit sleeves, 0 to 33% cable fill
  • Sealing of single or grouped cables of various types; power, voice, data
  • Seal 2” (51 mm) or 4” (102 mm) trade size steel sleeves or conduit sleeves
  • Blank openings through common construction such as concrete or gypsum board

    • Features

  • Fast and easy installation – no special tools required
  • Intumescent – expands in all directions for a tough, tight seal
  • Re-installable – easy retrofitting of cables
  • Soft and resilient foam – conforms to cable surfaces
  • Smoke resistant – superior air leakage ratings
  • Convenient – sized for 2” (51 mm) and 4” (102 mm) EMT or conduit sleeves

    • Specification

  • Color: Red
  • Normal Density: 19 pcf (304 kg/m3)
  • Weight: 2 in. – 0.20 lb (91 g), 4 in. – 0.50 lb (227 g)
  • Expansion Begins: 350°F (176°C)
  • Volume Expansion: 10 X
  • In-Service Temperature: <130°F (54°C)
  • Shelf Life: N/A
  • VOC Content: N/A
